EXPLODED VIEW PARTS LIST
REF. NO DESCRIPTION PART NO. Q’TY
REMARK
51 HINGE PIN 603-D750-100 2
52 HINGE SPRING 603-DJ2500-209A 2
53 BELT 604-BJ1900-079 1
54 LIFTER SPRING 603-B300-029 1
55 E-RING WASHER 606-F200-011 2
56 AXIS 200-DJ1900-168 1
57 LINK BASE 100-B300-109 1
58 SCREW 602-SL24F-097 1
59 UP/DOWN REST(ALUMINUM) 300-DJ1900-205A 1
60 OILED PLATE(STEEL) 300-DJ2500-146 1
61 WASHER DIA 11MM 606-B300-028 1
62 NUT 601-B300-006 1
63 MICRO ADJUST SPRING 603-B300-034 1
64 MICRO ADJUST LEVER 100-B300-118 1
65 WASHER 606-HV3360-091 1
66 SCREW 602-B600-059 1
67 VELOCITY MODULATE PCB ASS'Y 704-BJ20-2401 1
68 CENTER SHAFT ASS'Y 703-BJ25-389 1
69 LUG TERMINAL ASS'Y 704-DJ1900-731 1
70 SCREW 602-B600-058 3
71 TONEARM SET XUSHIONC 612-DJ1900-024 1
72 SLIDE SW(T-876WF01RB UCV,6PIN) 403-DJ1900-029 1
73 FIXED AXES FOR FOOT CUSHION(COPPER) 200-DJ1900-164 4
74 SCREW 602-DJ1900-149 8
75 RUBBER FOOT(BLACK) 604-DJ1900-075 4
76 PLASTIC FOOT (ABS HOT STAMP) 100-DJ3110-590 4
77 CU(RUB) 612-3113-002 4
78 SCREW FOR FIXING MOTOR 602-SL24F-109 3
79 RUBBER FOOT FOR MOTOR 604-SL24F-038 3
80 LABEL 501-DJ2000B-1156 2
81 SAFETY PULLEY 100-DJ1900-593 3
82 AC POWER CORD(UL TYPE,L=2130+-50mm) 409-HMD5000-053 1 20A1
82 AC POWER CORD 409-3004-016 1 20B1
82 AC POWER CORD(L=2000+-50mm,BS TYPE) 409-HMD500B-037 1 20C1
83 LABEL 501-HV3500KB-1137 1
84 CUL LABEL 501-BJ1900W-1282A 1 20A1
84 LABEL FOR RATING 501-BJ20B-1496 1 20B1/C1
To Next Page
