9
Listening to the Radio
1. Set the Function selector to the Radio/Bluetooth position.
2. Select the desired frequency (AM or FM) using the FM/AM/Bluetooth switch (FM/Bluetooth on EU
units).
Note: EU units only can select FM.
3. Select the desired radio station by turning the Tuning knob.
4. Adjust the volume to the desired level.
5. When finished listening to the radio, set the Function selector to the OFF position to turn off the radio.
Note: The receiver has a built-in FM antenna hanging at the rear cabinet. This wire should be fully uncoiled
and extended for best reception.
Technical Specifications
Speaker Output Power
2W + 2W
Frequency Response
60-20,000 Hz
Motor
DC servo motor
Drive System
Belt drive
Speed
33-1/3, 45, 78 RPM
Output Level
500 m
@ 1 kHz
Impedance
4 ohm
Cartridge Type
Ceramic stereo cartridge
Supported Data CD File Types AAC/M4A, AIFF/AIF, MP3, WAV, WMA
Supported USB Flash Drive File Types
MP3, WAV, WMA
Voltage
120V AC, 50 Hz (US/CA)
230V AC, 60 Hz (EU)
Power Consumption 20W
Dimensions
(width x depth x height)
18.5" x 15" x 9.6"
47 cm x 38.1 cm x 24.3 cm
Weight
18.9 lbs; 8.6 kg
Specifications are subject to change without notice.
* Bluetooth range is affected by walls, obstructions, and movement. For optimal performance, place the product in the center
of the room so it is unobstructed by walls, furniture, etc.
Trademarks and Licenses
ION Audio is a trademark of ION Audio, LLC, registered in the U.S. and other countries.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by
ION Audio is under license.
All other product or company names are trademarks or registered trademarks of their respective owners.
