IONIC Zero PPM - Battery Charging Specifications

Maintenance Procedures – Battery Charging
40
Technical Specification
*Back Current Drain is what the charger uses to drain the battery if the power chord is disconnected
** Quality of the current and voltage are very important. High current ripple heats up the battery and makes the
positive electrode age prematurely. High Voltage ripple could harm other equipment connected to the battery, MULTI
XS 7000 produces a high quality current and voltage with very low ripple.
*** If the electrical plug is of the flat euro connector type, the battery charger has insulation class IP63, except in
Switzerland where IP65 is valid.
Battery Size (Ah)
Time to - 80% (Hours
20
3
60
18
100
12
225
25
Battery Condition Indicator
With mains power connected, indicates charge level of battery (see above diagram)
Mode Selection Button
Use to move between the various maintenance modes, the mode selected will be indicated
by the LED’s position.
Battery Information
- Batteries are only fitted to vehicle-mounted systems
- The battery should never be completely discharged through
exhaustive use
The position of the battery is referenced on page 10
The Battery will satisfy the machine’s requirements only when properly maintained.
Model
1007
Voltage
AC 170 - 260VAC, 50 - 60 Hz
Back Current Drain *
<1mA
Voltage Charging Voltage Nominal
12 v 13.6v; 14,4 v 12.7 v or 15.7 v
Ripple **
Max 150 mV rms, max 0.3 A (=4%)
Current
7A Max
Ambient Temperature
-20º to + 50º, Power is reduced automatically at in- creased
ambient temperature
Cooling
Natural Convection
Charging Cycle
Multi XS 7000 is a multi stage fully automatic charger
Type of Batteries
All types of 12v lead-acid batteries (wet, MF, AGM and GEL)
Battery Capacity
14-225 Ah
Dimensions
191 x 89 x 48 mm (L x W x H)
Insulation
1P65**
Weight
0.8kg
Battery Specification
100 ah
Ampere hour capacity at 20 hr rate
679
Cold Crank Performance
12 v
Potential Difference Voltage
Deep Cycle
Multi Function Leisure Battery
