For Bruker CaptiveSpray source.
Disassemble rear metal housing
of CSI probe insert (2 screws)
Carefully remove Aurora CSI protective
cap.
Insert Aurora CSI fitting into CSI probe.
Insert using a twisting motion to prevent
pinching of rubber seal.
Remove the protective plug from the
nanoZero® union.
Unscrew CSI probe from CSI housing
Feed Aurora column through the rear metal housing and reassemble CSI probe (2 screws),
ensuring rubber seal is in place between metal housing and Aurora CSI fitting.
Feed column through CSI housing and screw CSI probe insert into housing.
Feed Aurora column with nanoZero®
fitting through CSI probe housing.
The CSI housing is now ready to connect
to your LC-MS system.
3 4 5
6 6.1 7
8 8.1 9
1
2
