Section 1 Introduction
1.3b
Terminal Installation Category:
Standard:
Not Applicable.
CE:
Category 1 for all terminals.
Dimensions:
188 mm deep x 140 mm wide x 68 mm high (7.39" x 5.5" x 2.68").
Weight:
1.55 kg. (3.6 lbs).
Operating Environment:
Standard:
Indoor, 0
°
to 50
°
C; 0 to 70% RH to 35°C. Linearly derate 3% RH/°C from 35 to 50 °C.
CE:
Indoor use at altitudes below 2000 meters, 0
°
to 40
°
C; 80% maximum RH up to 31
°
C decreasing linearly 4%
RH/
°
C to 40
°
C.
Controls:
Power switch (external), and IEEE parameter switches (internal).
Indicators:
LED indicators for IEEE TALK, LISTEN, SRQ, ERROR, and POWER.
Power:
An external power supply is provided with the Digital488: Input is 105-125 VAC,
or 210-250 VAC; 50/60 Hz, 10 VA maximum. The external power supply 9 VDC output is to be connected to the
Digital488 power input marked: 10 VDC MAX @ 500 mA.
:$51,1*
Do not use this interface outdoors! The interface is intended for indoor use only!
Outdoor conditions could result in equipment failure, bodily injury, or death!
&$87,21
Do not connect AC power line directly to the Digital488. Direct AC connection will
damage equipment.
