Weight (kg/lbs) 34lbs/15.5kg
Enclosure NEMA 3R
Mount Wall mount
Communication Option
Wireless Network 2.4GHz Wi-Fi (802.11 b/g/n) (Optional)
Wide Area Network 4G LTE (Optional)
LAN 10/100 Ethernet
RFID Reader ISO 15693, 14443A/B
User Interface & Control
LED Indicators
Available (white), Charging in progress (pulsing in green), Charging complete (green),
Charging paused (blue), Unplug and try again (orange), Fault (red)
Safety
Codes and Standards SAE J1772
Safety Compliance UL listed for US/CA ; complies with UL 2594, UL 2231, UL1998, UL991
EMC Compliance FCC Part 15 Class B
Surge Protection
6kV @ 3000A. In geographic areas subject to frequent thunderstorms, supplemental
surge protection at the service panel is recommended.
