26
See the table below showing the available options and required (125%) breaker sizes.
Current
selection
switch
setting
Maximum
Output Current
Required Branch
circuit and
Breaker Rating
0 10A 15A
1 12A 15A
2 16A 20A
3 20A 25A
4 24A 30A
5 32A 40A
6 40A 50A
7 48A 60A
8 63A 80A
9 80A 100A
Table 1 - Current Selection and Branch Circuit Rating
