If the cable comes in from the bottom
1. Insert the power cable from the hole you
have drilled for it and pull it into the
terminal cabinet.
2. Secure the 3 wires in the order as shown
below.
NOTE: If necessary, apply proper cable ties
or clamps to secure the cables and to relieve
cable strain added on the terminals.
Re-install the cabinet cover
