Rotary switch Setting
This is for setting the rotary switch to limit the charging current.
A. Open the electrical box
1. Using a T20 Torx screwdriver, unscrew the
eight Phillips screws as shown below.
2. Open the box cover in the way as shown
below.
There are cables connected to cover.
Open cover with care.
