Front bin:
• Use the handle to release the bin (fig. B, ref. 12) 512-712.
• Use the handle to release the bin (fig. B, ref. 13) 512-712 RIDER.
• Grip the bin and slide it out
• Empty the bin.
• Replace the bin.
• Use the handle to block the bin in place (fig. B, ref. 12) 512-712
• Use the handle to block the bin (fig. A, ref. 13) 512-712 RIDER
Rear bin:
• Release the bin by lifting and turning the two clips (fig. B, ref. 13) 512-712.
• Release the bin by lifting and turning the two clips (fig. A, ref. 14) 512-712 RIDER.
• Grip the bin and remove it from the machine.
• Empty the bin.
• Replace the bin.
• Block the bin in place by turning the two clips and pressing them when in position.
Stopping:
• Move the machine to the parking area
• Stop the machine by releasing the handle (fig. B, ref. 9) 512-712, releasing the
accelerator knob (fig. A, ref. 9) 512-712 RIDER.
• Turn off the brushes using the button (fig. C, ref. 3) 512-712 RIDER .
• Stop suction (fig. C, ref. 9) 512-712
• Lift the side brush using the lever (fig. A/B, ref. 11).
• Turn the key switch (fig. C, ref. 1) to the "0" position.
7. PERIODS OF INACTIVITY
• Disconnect the battery. To optimise the working life of the battery, it should be charged
every 30/40 days. If the level of solution is low, top up with distilled water.
• Empty the bins.
• Clean the machine in general.
• Clean the suction filter.
8. MAINTENANCE INSTRUCTIONS
! DANGER
Maintenance on the electrical circuit and all other operations not explicitly
described in this manual must be performed by specialised personnel only, in
