6) Referring to the arrangement of cables shown in the diagram (fig. D), connect the
battery cable and bridge terminals to the battery poles.
Arrange the cables as shown in the diagram (fig. D), tighten the terminals on the poles
and cover with Vaseline.
7) Lower the tank into the working position
8) When using the machine, follow the instructions below.
5.5. The battery charger
IMPORTANT
Never allow the batteries to become excessively flat as this could damage them
irreparably.
5.5.1. Choosing the battery charger
Make sure the battery charge is compatible with the batteries to be charged:
− tubular lead batteries: an automatic charger is recommended
− Consult the battery charger manufacturer and manual to confirm the choice.
− gel batteries: use a charger specific for this type of battery.
5.5.2. Preparing the battery charger
If you wish to use a battery charger not provided with the machine, you must fit it with the
connector supplied with the machine.
To install the connector, proceed as follows:
• remove about 13 mm of protective sheath from the red and black wires of the battery
charger;
• insert the wires into the connector contacts and squeeze them forcefully with suitable
pliers;
• respect the polarity (red wire + black wire -) when inserting the wires into the
connector.
• Insert the wired-up connector into the connector on the machine (fig. C, ref. 4).
5.6. Lifting and transporting the machine
IMPORTANT
All phases must be performed in an adequately lit room and adopting the safety
measures most appropriate to the situation.
The operator must always use personal protection devices.
To load the machine onto a means of transport, proceed as follows:
• empty the collection and solution tanks;
• remove the squeegee and brushes (or abrasive disks);
• remove the batteries;
• place the machine on the pallet and fix it with plastic straps or metal brackets;
• lift the pallet (with the machine) using a fork lift truck and load it onto the means of
transport;
• anchor the machine to the means of transport with cables connected to the pallet and
machine itself.
