8.4. Replacing/installing the suction filter.
! DANGER
This operation must be performed with the machine off and ignition key removed
Every 50 working hours or as necessary, check the suction filter as follows:
• Lift the back guard (suction fan housing) (fig. I). Make sure it is blocked in the open
position by the safety device (fig. V).
• Unscrew the four screws (fig. L).
• Disconnect the connector on the filter shaker (fig. L).
• Remove the filter from its housing (fig. L).
• Thoroughly clean the filter with a vacuum cleaner or replace it (fig. M).
• To mount the filter, follow the same procedure in reverse.
• Close the back guard by releasing the safety device (fig. V).
8.5. Fuses: replacing
 IMPORTANT
This operation must be performed with the machine off and ignition key removed
• turn the ignition key (fig. C, ref. 1) to the "0" position.
• lift the fuse compartment cover (fig. C ref. 18 - fig. N).
• check the fuses (fig. N).
• replace with a new fuse.
• close the cover.
Fuse table: For the complete fuse table, see the spare parts catalogue.


 IMPORTANT
Never use a fuse with a higher amperage than specified.
If a fuse continues to blow, the fault in the wiring, boards (if present) or motors
must be identified and repaired. Have the machine checked by qualified personnel.
8.6. Replacing/installing flaps
! DANGER
This operation must be performed with the machine off and ignition key removed
Every 50 working hours or as necessary, check the flaps and if worn, proceed as follows:
8.6.1. Side flaps
• Open the side guards (fig. O - fig. P).
• Using a screwdriver, unscrew the flap fixing screws (fig. O - fig. P).
• Replace the worn flaps (fig. O - fig. P).
To mount, follow the same procedure in reverse.
8.6.2. Rear flap
• Remove the left side guard (fig. E).
• Remove the brush compartment cover (fig. F).
• Remove the rear flap (fig. Q, ref. 1).
• Replace the worn rear flap (fig. Q, ref. 1).
To mount, follow the same procedure in reverse.
8.6.3. Front flap
• Remove the two side brushes (fig. H).
• Using a screwdriver, unscrew the worn front flap fixing screws (fig. Q - ref. 2).
• Release the flap from the pronged clip.
