IPC CT15 - CT30 TECHNICAL SPECIFICATIONS

GB
CT30 TECHNICAL SPECIFICATIONS
CT30 B45 CT30 C45
Cleaning width mm 455
Squeegee width mm 545
Cleaning capacity per hour m
2
/h 1670
Number of brushes n° 1
Brush diameter mm 455
Maximum brush pressure g/cm
2
/
Brush rotation speed g/1° 140 140
Brush motor power W 350 400
Drive motor power W /
Maximum speed Km/h /
Suction motor power W 550 400
Solution tank L 28
Dirty water tank L 30
Rear wheel diameter mm 250
Maximum slope % 2
Gross weight Kg 126 81
Transported weight Kg 76 28
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 100-240
115
220
Machine dimensions mm
X=850
Z=1220
Z1=745
Y=568
Battery compartment dimensions
(length, width, height)
mm 240x330x220 /
Packed size (length, width, height) mm 900x610x960
Sound pressure (EN 60704)
LpA
(dBA)
≤70 72
Measurement uncertainty
K
(dBA)
2,5 2,5
7
