6.5.2 LAN Configuration
The LAN connections are used for communicating with an IP KTU and/or a PC connected to the
LAN ports of RSGM.
Assign an IP address to the LAN Ethernet port. This IP address is also the default router address
for the devices on the private (local) LAN. The default LAN interface IP address is set to
10.10.50.50. Enter the subnet mask for the private LAN. If you wish to set the broadcast and
multicast limits, enter these values as percentages of the LAN interface Ethernet bit rate. Leaving
these values blank will imply values of 100%.
LAN Settings
DHCP settings allow configuration of the private LAN DHCP server. Specify whether the device’s
internal DHCP server feature is enabled or disabled. Also, indicate the IP address range to use
for DHCP assignments to the LAN. Specify the domain name (optional) that is provided to LAN
clients via DHCP. Two optional static DNS server IP addresses can be entered that will be
provided to LAN clients via DHCP. These are in addition to the DNS servers automatically
provided by WAN connections.
DHCP Settings
Via the Web configuration, up to eight static DHCP addresses can be configured. User can add or
remove static assignment entries, and view the current active DHCP client-binding table. The
device’s internal DHCP client binding table cleared, but be aware that doing this will destroy the
DHCP server’s knowledge of the LAN clients it has provisioned, and may result in client problems
when a client tries to renew its lease.
Port Forwarding allows configuration of the device’s port forwarding feature. Port forwarding
provides WAN access to the internal LAN, by specifying that traffic over certain ports are to be
directed at particular LAN hosts. Up to eight port forwarding entries ("Pinholes") can be configured.
To add a port forwarding entry configure the Port Range to be forwarded, the Protocol to be forward
(TCP, UDP or both), and destination LAN IP Address to be used. User may also remove specific
entries. Note that certain port numbers may be reserved by the CPE for its own internal use.
These ports may not be used for port forwarding to the LAN. Ports which may be reserved by the
CPE include those used by iPECS signaling, RTP packets, HTTP, etc. All reserved (unavailable)
ports will be displayed on this page.
Port Forwarding Settings
Router settings allow configuration of the device’s core router functionality. If you wish for the
router to update its routing tables dynamically, specify whether RIPv2 dynamic routing information
is to be received or transmitted (or both). In addition, up to eight static route entries can be
assigned via Web configuration. To add a static route, enter the static route Destination IP
address, subnet Mask, gateway IP Address, metric, and interface. Metric is a number from 1 to 15
inclusive. Users may also remove specific entries or view current internal routing table.
Router Settings
VLAN settings allow configuration of VLAN tag and/or Priority tag for all outgoing packets.
VLAN Settings
