RSGM Installer Guide
6
The following Table 2.2-1 describes the various LEDs which provide visual representation of the
RSGM activity and status.
Indicators
Table 2.2-2 RSGM Activity & Status LEDs
Name LED Color Status Description
POWER RED
ON
Power On
OFF No Power
LINK/ACT GREEN
ON Valid LAN Link
OFF
Link Fail
FLASH TX/RX Activity
10/100 YELLOW
ON 100 MBPS
OFF 10 MBPS
LAN POWER RED
ON Supplying power to LIP phone
OFF
Not supplying power to LIP phone
CO RED
ON CO Line in Use
OFF CO Line Idle
FLASH CO Line Ringing
CMU RED
ON CMU Installed
OFF
CMU Not Installed
SLT RED
ON SLT in Use
OFF SLT Idle
FLASH SLT Ringing
MSG RED
ON SLT Message Waiting Message
OFF
Message Idle
IP KTU RED
ON IP Phone in Use
OFF IP Phone Idle
FLASH IP Phone Ringing
BGM RED
ON BGM Activity
OFF
BGM Idle
S1 RED Future Use S1
S2 RED
ON WAN DISCONNECTED Mode
FLASH RSGM WAN connected
