Alarm Input Setting
Among alarm input setting, the user can setup the connected device which
can send the signal to “relay output” when the device is triggered.
Relay Output Setting
In relay output setting, the user can setup the output device to perform the
related output action.
(1) Non-Triggered
(2) Triggered
Sensor
Device
ALARM
GND
3.3V
Sensor
Device
ALARM
GND
0V
3.3V
3.3V
Triggered
