15. Technical specification
Model
IQSW-GSM-F, IQSW-GSM-E
Input power socket
230V / 50Hz
Output power socket
230V , CEE 7/4 German "Schuko" earthed
230V, CEE 7/4 French type
Data interfaces
GSM SIM socket
Switching
Output 1: Relay, 230V/16A (2s), 10 A long-term
Output 2 : microrelay, max. 50V / 0,5 A
Management
SMS configuration, SMS parameters monitoring
Indicators
POWER: two-color LED
GSM: green LED
RELAY: yellow LED
Detectors
Built-in thermometer
Alarm input for external detectors (motion, gas, water, fire,
door/Windows and more.)
GSM
900 / 1800 /1900 MHz
SIM card Plug-in 3V
Integrated tape microstrip antenna
GPRS
Not supported
Software features
Appliance control over SMS, by call or manually
Remote power turnon/turnoff of 230V appliance
Remote power turnon/turnoff of output circuit up to 48V
Remote power turnoff for specified time
Remote appliance restart
Remote appliance status switch (turnon to turnoff or back)
Remote temperature measuring
Thermometer, Alarm detection, Scheduler
Power
230V , CEE 7/7
Weight Netto / Brutto
350g / 420g
Operating temperature
-10 to +50 ˚C
16. Care and security recommendations
Product was designed for indoor use. Don’t use it in wet or chemically
aggressive environment. It is also not designed for industry operation with
aggressive environmental conditions. Don’t let the product to get in shaking or
fall downs, otherwise it can be damaged. Please check, if mobile phones can be
used in the area before use. In not, don’t put product into operation, it can
have negative influence to other electronic systems.
Improper use, disassembling or product modification causes warranty
loss. Product doesn’t guarantee safe power source interruption, only functional
switching is realized.
