iRay Technology GL35R - 17 Wi-Fi Function

InfiRay Outdoor • Geni GL35R Series • Quick Start Guide www.infirayouordoor.com
All rights reserved and shall not be copied and distributed in any form without written permission
Return
Return to the main menu
➢ Select the Return option by Z (5) / C (3) button.
➢ Short press the M (4) button to return to the main menu.
16 PIP Function
➢ In the home screen, press and hold down the M (4) button to enter the
Main Menu.
➢ Select the PIP option with the Z (5) / C (3) button.
➢ Briefly press of the M (4) button to turn PIP on/off.
➢ When the PIP function is on, a small window will appear on the top of the
display.
➢ The image in the small window is a 2x magnified image centered by the
reticle center.
➢ When the main image is enlarged through Z (5) button, the PIP image
will be enlarged 2× synchronously.
17 Wi-Fi Function
The device is equipped with wireless communication with external
devices (computer, smartphone) via Wi-Fi.
➢ In the home screen, press and hold the M (4) button to enter the menu.
➢ Select the Wi-Fi option with the Z (5) / C (3) button.
➢ Briefly press of the M (4) button to turn Wi-Fi on.
➢ The device is recognized by an external device under the label
‘Geni_xxxxx-xxxxxxʼ, xxxxx-xxxxxx is the SN code of the device.
➢ Enter the password on an external device, and establish a connection.
The initial password is 12345678.
➢ And then, the device can be controlled through the InfiRay Outdoor.
Set Wi-Fi name and password
The Wi-Fi name and password of your device can be set in the APP.
