6 iRobot Dirt Dog Owner’s Manual
Anatomy
Top View
Bottom View
Cleaning
Button
Virtual Wall
Sensor
Bin Release
Battery Charger
Socket
Serial Port
Handle
Flexible
Brush
Main
Brush
Cliff Sensor
Openings
Edge-Cleaning
Side Brush
Contact
Points for
Home Base
Brush Guard Release Tabs
(yellow)
Brush
Bearings
Brush
Guard
Caster Wheel
Battery
Brush
Caps
