iRobot Roomba 960 Vacuum - Robot Anatomy; Top View; Buttons & Indicators; Bottom View

PAGE 3 OF 8 0117 IH-6472
ROBOT ANATOMY
Handle
TOP VIEW BUTTONS & INDICATORS
iAdapt® Localization Camera
Bin Release Button
CLEAN Button
SPOT ButtonDOCK Button
Battery Indicator
Full Bin Indicator
Dirt Detect™
Indicator
Wi-Fi
®
Indicator
Troubleshooting
Indicator
BOTTOM VIEW
Extractor Caps
Debris Extractors
Extractor Frame
Release Tabs
Side Brush
Charging Contacts
Floor Tracking Sensor
Dust Bin
Extractor Frame
