ISA DRTS.3 PLUS - Battery Simulator

Doc. SIE62153 Rev. 1 Page 16/24
STANDARD
D
RTS.3
PLUS
D
RTS.3
PLUS
-
HP
OUTPUT CURRENT
Typical: ± 0.05% ± 0.01% of
range
T
ypical: ± 0.02% from 0.1 to 15
A
Maximum: ± 0.1% ± 0.02% of
range
Maximum: ± 0.05% from 0.1 to
15 A
OUTPUT VOLTAGE
Typical: ± 0.05% ± 0.01% of
range
Typical: ± 0.02% from 50 to
300 V
Maximum: ± 0.1% ± 0.02% of
range
Maximum: ± 0.05% from 50 to
300 V
PHASE ANGLE
Typical: ± 0.02°
Maximum: ± 0.1°
Typical: ± 0.01°
Maximum: ± 0.02°
POWER
; SEE TABLE
Typical: ± 0.05%
Typical: ± 0.05%
Maximum: ± 0.2%
Maximum: ± 0.1%
NOTES
1) The above accuracies are obtained in the following operating conditions:
. Output frequency: 40 to 60 Hz;
. Temperature: 20 °C to 25°C;
. Power supply: 210 to 240 V;
. Burden: less than 30% of the maximum.
2) The rated power accuracy applies to p.f. = 1; the accuracy at other p.f. is shown here below.
p.f.
1
0,8
0,5
0,1
0
Max. err
or for std. DRTS.3
PLUS, %
0,2
0,25
0,27
1,1
Infinite
Max error for DRTS.3 PLUS
-
HP, %
0,1
0,125
0,135
0,55
Infinite
3) The rated power accuracy applies for currents greater than 0,1 A and voltages greater than 10 V.
4.4 Battery simulator
- Output connection: two safety banana sockets.
- A light turns on when the output is applied.
- Output voltage range: 260 V D.C..
- Output programmable from 0 to maximum value, with resolution of 1/2047rd of the range,
corresponding to 63 mV.
- Possibility of stepping the selected value. NOTE: the velocity of variation is affected by the
capacitance of the load, that is charged with the current output of 2 A.
- Possibility to ramp the voltage. Velocity of variation is between ± 0.1 V/s and ± 999 V/s. Voltage
changes occurs every 10 ms.
- Output power: 100 W or 2 A; continuous duty.
