5.2.2 Two phase voltage generator
- Two independent voltage sources, with a common neutral.
- Type of connection: safety banana plugs.
- Output ranges, and corresponding power and resolution of AMIV-66 alone.
RANGE
OUTPUTS
CONNECTION
VOLTAGE
(V)
POWER
(VA)
Z MAX
(Ohm)
RISOLUT.
1 2 X DIRECT 0…125 80 195 1.9 mV
2 2 X DIRECT 0…12,5 195 190
µ
V
3 2 X DIRECT 0…1 195 19
µ
V
4 1 X 2 IN SERIES 0…250 160 390 3.8 mV
5 1X 2 IN PARALLEL 0…125 160 97 1.9 mV
OPTIONAL 300 V OUTPUT
1 2X DIRECT 0…300 80 1125 4.6 mV
2 2X DIRECT 0…125 80 195 1.9 mV
3 2X DIRECT 0… 12.5 195 190
µ
V
4 1X 2 IN SERIES 0…600 160 390 9.2 mV
5 1X 2 IN PARALLEL 0…300 160 97 4.6 mV
- Output ranges, and corresponding power and resolution of AMIV-66 with DRTS3 PLUS.
RANGE
OUTPUTS
CONNECTION
VOLTAGE
(V)
POWER
(VA)
Z MAX
(Ohm)
RISOLUT.
1 6 X DIRECT 0…125 80 195 1.9 mV
2 6 X DIRECT 0…12,5 195 190
µ
V
3 6 X DIRECT 0…1 195 19
µ
V
4 1 X 2 IN SERIES-PAR. 0…250 320 195 3.8 mV
5 1X 4 IN PARALLEL 0…125 320 50 1.9 mV
OPTIONAL 300 V OUTPUT
1 6X DIRECT 0…300 80 1125 4.6 mV
2 6X DIRECT 0…125 80 195 1.9 mV
3 6X DIRECT 0… 12.5 195 190
µ
V
4 1X 4 IN SERIES-PAR. 0…600 320 195 9.2 mV
5 1X 4 IN PARALLEL 0…300 320 50 4.6 mV
- Output frequency: from DCto 2000 Hz; transient 5 kHz.
- Waveform resolution: 28 bit (16 for the amplitude, 12 for the shape).
- Output accuracy: ± 0.1% of the output ± 0.02% of the range.
- Distortion: 0.1% total maximum, with any load.
- Automatic protection for overloads and counter-feed.
- Angle accuracy: ± 0.05°.
5.2.3 Power supply
- Mains power supply: 90 to 264 V a.c., single phase.
- Frequency: 47 to 63 Hz.
