iScan DSF-2010-MB - Non-Hazardous Area Model (PN 2653-271-12) General Arrangement; Hazardous Area Model (PN 2653-271-05) General Arrangement

RELATED DOCUMENT – MUST COMPLY WITH SCHEDULE DOCUMENT(S):
MNL-ISCANMB
FOR A LIST OF RELEVANT PATENTS
AND TRADEMARKS PLEASE SEE
CHENTRONICS.COM/LEGAL-NOTICES
INSTALLATION & OPERATION MANUAL
PAGE 22 OF 24
ISO 9001 CERTIFIED
DRAWN BY:
AR
ON:
2022-NOV-01
LAST REV BY:
ON:
DCO No.
15137
DWG. No. MNL-ISCAN2MB
REV. J
THIS DRAWING OWNED BY CHENTRONICS. IT IS
CONDITIONALLY LOANED AND IS TO BE RETURNED UPON
REQUEST. THE BORROWER BY RECEIVING IT HAS AGREED
NOT TO REPRODUCE NOR COPY IT IN WHOLE OR IN PART NOR
TO FURNISH INFORMATION FROM IT TO OTHERS NOR TO
MAKE ANY USE OF IT THAT IS OR MAY BE INJURIOUS TO
CHENTRONICS. FOR MORE INFORMATION PLEASE CONTACT
CHENTRONICS AT +1.607.334.5531.
TOLERANCE NOTES
FABRICATED TOLERANCES
≥ 2 ft (610 mm) ± 0.250 in (6.4 mm)
< 2ft (610 mm) ± 0.125 in (3.2 mm)
MACHINED TOLERANCES
± 0.050 DECIMAL DIM (1 PLACE)
± 0.010 DECIMAL DIM (2 PLACES)
± 0.005 DECIMAL DIM (3 PLACES)
INSTALLATION & OPERATION MANUAL
6.3 Non-hazardous Area Model (PN 2653-271-12) General Arrangement
6.4 Hazardous Area Model (PN 2653-271-05) General Arrangement
Swivel Mount
Hazardous Area Scanner
Integrated Cable
Mounting Ring
Optional IR Filter
Optional Ball Valve
Purge Air Connection
Mounting Ring
Input Cable
Non-hazardous Area Scanner
Swivel Mount
OPTIONAL IR Filter
I
OPTIONAL Ball Valve
I
Purge Air Connection
