iScan DSF-2010-MB - Non-Hazardous Area

RELATED DOCUMENT – MUST COMPLY WITH SCHEDULE DOCUMENT(S):
MNL-ISCANMB
FOR A LIST OF RELEVANT PATENTS
AND TRADEMARKS PLEASE SEE
CHENTRONICS.COM/LEGAL-NOTICES
INSTALLATION & OPERATION MANUAL
PAGE 6 OF 24
ISO 9001 CERTIFIED
DRAWN BY:
AR
ON:
2022-NOV-01
LAST REV BY:
ON:
DCO No.
15137
DWG. No. MNL-ISCAN2MB
REV. J
THIS DRAWING OWNED BY CHENTRONICS. IT IS
CONDITIONALLY LOANED AND IS TO BE RETURNED UPON
REQUEST. THE BORROWER BY RECEIVING IT HAS AGREED
NOT TO REPRODUCE NOR COPY IT IN WHOLE OR IN PART NOR
TO FURNISH INFORMATION FROM IT TO OTHERS NOR TO
MAKE ANY USE OF IT THAT IS OR MAY BE INJURIOUS TO
CHENTRONICS. FOR MORE INFORMATION PLEASE CONTACT
CHENTRONICS AT +1.607.334.5531.
TOLERANCE NOTES
FABRICATED TOLERANCES
≥ 2 ft (610 mm) ± 0.250 in (6.4 mm)
< 2ft (610 mm) ± 0.125 in (3.2 mm)
MACHINED TOLERANCES
± 0.050 DECIMAL DIM (1 PLACE)
± 0.010 DECIMAL DIM (2 PLACES)
± 0.005 DECIMAL DIM (3 PLACES)
INSTALLATION & OPERATION MANUAL
3.3 Non-hazardous Area
The iScan2 DSF-2010 system has been assessed and complies with the following safety standards:
NEC/CEC/ABS/CE/UKCA
NEMA TYPE 4X
SIL 3
20140305-MH26433
21-2116223-PDA
NB 2797 705806
AB 0086 751491
FM3610:2009UL, FM7610:1997 60730-2-5
CAN/CSA C22.2 No. 199-2007 ANSI Z21.20
IEC 61508-1:2010, IEC 61508-2:2010, IEC 61508-3:2010
EN 298:2012, EN 63000, EN 61000-6-4, EN 61000-6-2
