INSTALLATION & OPERATION MANUAL
4 General
4.1 Product Description
The iScan2 is designed for detecting burner flames of fossil fuels such as hydrogen blends and 100%
hydrogen, natural gas, refinery gas, waste gas, fuel oils, biomass and coals. The iScan2 flame scanner
consists of an integrated viewing head and signal processor. No secondary signal processor or amplifier is
required.
4.2 Views of Models
4.2.1 Non-hazardous Area (PN 2653-271-12)
4.2.2 Hazardous Area (PN 2653-271-06)
