04
Put the fender through the front fork. Reinstall the
bolts, Washers and nuts (in this order). Reinstall
the lower fender screws.
2
Take out the front fender and remove the nuts,
Washers and bolts on the top and bottom of the
front fork.
Step 4 Front Light and Mudguard Installation
Warnings:
● The disc brake is located on the left side in the direction of riding.
● Make sure the front wheel hub is fully engaged into the front fork drop-outs.
● Ensure that the circumference of the front wheel is completely caught in the drop-outs of the
front fork, and tighten the nuts on both sides. Recommended torque is 30 ~ 40 NM.
1
