iSinwheel EBIKE D4 - Handlebar Angle Adjustment; Front Wheel Installation

03
Put the front fork on the front wheel.
Make sure the brake caliper clamps
the brake rotor and keep the fork
drop-outs to stay on the axle.
4
Insert the QR skewer through
the axle and tighten the
adjusting nut.
5
Use your palm to close the
QR lever.
6
Step 3 Front Wheel Installation
Take out the front wheel and
QR skewer.
1
Loosen the nuts of the fork
mount and remove the fork
mount.
2
Loosen the adjusting bolt of the QR
skewer, Make sure the smaller end
of the 2 cone springs facing inwards.
3
Step 2 Handlebar Angle Adjustment
Make sure the handlebar is perpendicular to the
front wheel.
2
To adjust the handlebar angle, Open the quick
release connecting the handlebar and stem.
1
