03
2.2 Install the front fender
1. Remove the bolt pre-installed
on the joint of the front fork legs
and steerer tube.
2. Find the front fender. Pass the bolt through the washer, fender bracket, and
front fender mounting hole in sequence. Tighten the nut with an appropriate hex
wrench and open-end wrench.
3. Tighten the bolts holding the
front fender stay with a hex
wrench.
1
3
2
