Iskra MC320 User Manual

CONNECTION

Measuringcentres–M
C
320,MC330,MC350&MC350H ‐ User’sManual 1
7


Digital input module with two digital inputs
enablesreceptionofimpulsesignals.(MC350,
MC350HandMC330only).

Digital input module with two digital inputs
enablesreceptionofimpulsesignals.(MC350,
MC350HandMC330only).

Digital input module with two digital inputs
enablesreceptionofimpulsesignals.(MC350,
MC350HandMC330only).

Analogue output module with two analogue
outputs(0...20mA), proportionaltomeasured
quantities. (MC350, MC350H with high range
aux.powersupplyonly)
Communicationconnection
Atypeofconnectordependson orderedcommunicationtype. RS232,RS485andM‐Buscommunicationare
equippedwithscrewterminalconnector,ProfibuswithD‐SUB9pinconnector,USBwithUSBstandardBtype
terminalandServiceUSBportwithmini‐Btypeterminal.

WARNING!

WhenconnectingacommunicationconnectoritisnecessarytoassurewhichtypeRS232or
RS485 or M‐Bus communication is used. Otherwise the communication module can be
damagedordestroyed.Seeconnectiondiagramsbelow.

4 Corresponding data are stated on the instrument label, regarding the selected communication.
Connectorterminalsaremarkedonthelabelontheuppersideof the instrument. More detailed
informationoncommunicationisgiveninchapterCommunicationonpage50.
RS232
RS232communicationisintendedfordirectconnectionoftheMeasuringcentretothepersonalcomputer.For
properoperationitisnecessarytoassurethecorrespondingconnectionofindividualterminals(seetableonnext
page).
RS485
RS485 communication is intended for connection of devices to network where several devices with RS485
communicationareconnectedtoacommoncommunicationinterface.WesuggestusingoneoftheISKRA,d.d.
communicationinterfaces!
M‐Bus(MC350andMC350Honly)
M‐BusslaveinterfaceisintendedforconnectiontonetworkwhereM‐Busmasterdeviceispresent.Formore
informationregardingM‐BuspleaserefertoAppendixDonpage68.
Profibus(MC330,MC350andMC350Honly)
ProfibusDP‐V0communicationprotocolissupported.Upto32slavedevicescanbeconfiguredintothesingle
Profibusnetwork.Eachdevicecanbeconfiguredasaslavedeviceprovidingwiderangeofmeasuringdatatothe
Profibusmaster.FormoreinformationregardingProfibuspleaserefertoAppendixConpage63.

