Iskra MC320 - Pulse (S0) Module; Relay (Alarm) Module (MC350, MC350 H and MC330 Only); Functions of Output Modules (Pulse and Relay)


SETTINGS

34 Measuringcentres– M
C
320,MC330,MC350&MC350H‐User’sManual


Relayoutputandapulse outputcanalsobeselectedviaakeyboard.Whenselectingsettingsofenergy and
quadrantsforacertaincounter,onlypresentselectionispossible,whilemoredemandingsettingsareaccessible
viacommunication.

MC320onlysupportspulseoutputandtariffinputmodules;PleaseseechapterTypedifferences,pages11.
Pulse(S0)module  
Itisasolidstate,optocoupleropencollectorswitch.Itsmainintentionistobeusedasapulseoutputforselected
energycounter,butcanalsobeusedasanalarmorgeneralpurposedigitaloutput.
FordescriptionofoutputfunctionalityseechapterFunctionsofDigitaloutput(PulseandRelay)modulesbelow.
Relay(alarm)module(MC350,MC350HandMC330only)  
Itisarelayswitch.Itsmainintentionistobeusedasanalarmoutput,butcanalsobeusedasapulseorgeneral
purposedigitaloutput.
AparallelRCfilterwithtimeconstantofatleast250μs(R∙C≥250μs)shouldbeusedincaseofasensitivepulse
counter.RCfilterattenuatesrelaytransientsignals.
FordescriptionofoutputfunctionalityseechapterFunctionsofDigitaloutput(PulseandRelay)modulesbelow.
Functionsofoutputmodules(PulseandRelay)  
ToDigitaloutputs,PulseandRelay,differentfunctionscanbeattached.AllcanbesetwithMiQensoftware.
PULSEOUTPUTOFENERGYCOUNTER
Acorrespondingenergycounterisdefinedtoapulseoutput.Anumberofpulsesperenergyunit,pulselength,
andatariffsinwhichoutputisactiveareset.

WARNING!

PulseparametersaredefinedbyEN62053−31standard.Inchapter Calculaon of
recommendedpulseparameters,belowasimplifiedruleisdescribedtoassistyouinsetting
thepulseoutputparameters.
MainmenuSettingsInputs/OutputsI/O1/2/3/4SettingofpulseoutputOK
Thepulsemodulecanalsofunctionasanalarmoutputwithmaximumcurrentload30mA.
CALCULATIONOFRECOMMENDEDPULSEPARAMETERS
Number of pulses per energy unit should be in certain limits accordingtoexpectedpower.Ifnotsothe
measurement from pulse output can be incorrect. Settings of current and voltage transformers can help in
estimationofexpectedpower.

Principle described below for pulse setting, where e is prefix, satisfies EN 62053‐31: 2001 standards pulse
specifications:
eWh1p100eW155,1 

Examples:
Expectedpower

Pulseoutputsettings
150‐1500kW

1p/1kWh
1.5‐15MW

100p/1MWh
15‐150MW

10p/1MWh
150‐1500MW

1p/1MWh
CALCULATIONOFRECOMMENDEDPULSEPARAMETERS
IfDigitaloutputisdefinedasanAlarmoutput,itsactivity(trigger)isconnectedtoAlarmgroups.Multiplealarm
groupscanbeattachedtoitanddifferentsignalshapesdefined.Formoreinformationonhowtodefinealarm
groups,seechapterAlarmsonpage36.
