APPENDIXD:M‐BUS

7
0
 Measuringcentres
–
MC320,MC330,MC350&MC350H‐User’sManua
l

ActivePowerTotalPt(W)
Activepowertotalin32bitx10
(nnn‐3)
W
 DIF DIFE DIFE VIF VIFE DATA
 04  00101nnn
b
xx.xx.xx.xx
n‐0…7

ReactivePowerTotal(kvar)
Reactivepowertotalin32bitx10
(nnn‐3)
var
 DIF DIFE VIF VIFE VIFE VIFE DATA
 04 FB 97 01110nnn
b
xx.xx.xx.xx
n‐0…7

InstantApparentPowerTotal(VA)
Apparentpowertotalin32bitx10
(nnn‐6)
VA
 DIF DIFE VIF VIFE VIFE VIFE DATA
 04 FB B4 01110nnn
b
xx.xx.xx.xx
n‐0…7

PowerFactor:‐:leadinget+:lagging:PF
Powerfactoras32‐bitinteger*10
‐3

 DIF DIFE DIFE VIF VIFE VIFE VIFE DATA
 04  A8 B4 35 xx.xx.xx.xx
Unit:W/V/A

CurrentTotal(A)
Totalcurrentas32bitx10
(nnnn‐12)
A
 DIF DIFE VIF VIFE VIFE DATA

 04  FD 0101nnnn
b
  xx.xx.xx.xx
n‐0…15

Systemfrequency(Hz/1000)
Containsthelinefrequency32‐bitintegerinmHz.
 DIF DIFE DIFE VIF VIFE VIFE VIFE DATA
 04  FB 2C xx.xx.xx.xx

ActivePowerinPhase1,2,3(W)
Activepowerin32bitx10
(nnn‐3)
W
 DIF DIFE DIFE VIF VIFE VIFE DATA
 04  xx.xx.xx.xx
P1:   10101nnn
b
FC 01
P2:   10101nnn
b
FC 02
P3:   10101nnn
b
FC 03
n‐0…7


