Step 3 of 13
Handlebar set up
3.1. Turn handlebars clockwise and align with front wheel.
3.2. Tighten the two stem clamp bolts Max. 7Nm.
3.1. Turn
3.2. Tighten
Do not adjust headset bolt during initial setup unless:
Handlebar height adjustment is necessary. See step 4.
Play is detected in the headset.
Headset bolt
3.3. Check the stem is tight by
standing at the front of the
bike with the wheel clamped
between your legs. While
holding the grips, gently try
to turn the handlebars. The
handlebars should not move
independently to the wheel.
