Retting the rear wheel
1. Check that the motor wire shield is still tted.
OK
3. Line up outer sprocket from the cassette with the chain and push the
axle up into the dropouts.
4. Align shaped washers correctly and torque up wheel nuts to 35Nm.
2. Always ensure that the motor
cable is correctly attached
to the rear wheel axle and is
facing downwards.
OK
5. Re-attach the motor cable.
You must ensure that the orientation arrows on the plug and socket
are aligned whilst doing this to ensure that the cable is not damaged.
OK
