2 Sedona LCD Display
The display can be used as an operating panel to display and manage the algorithm of
the iSMA-B-AAC20 controller or to view and manage system settings.
The built-in display is a monochrome display with backlighting. It can display up to 20
characters per line and up to 7 rows on one screen. Up to 16 lines can be displayed in a
single screen, and scrolling is available with up/down arrows (one line at a time) or with
the keys F1/F2 (scrolling entire screens).
Note: The display supports only the basic ASCII characters.
There are 6 dedicated keys to operate the display:
Esc: exit key;
Enter: select, move the cursor to the right;
Arrow up: add/subtract, menu navigation;
Arrow down: add/subtract, menu navigation;
F1: function key;
F2: function key.
