11
Making Basic Measurements
Preparation and Caution Before Measurement
 : Observe the rules of
 Warnings and  Cautions
.
When connecting the test leads to the DUT (Device Under
Test) connect the common (COM) test lead before connect-
ing the live lead ; when removing the test leads removing the
test live lead before removing the common test lead.
The figures on the following pages show how to make basic
measurements.
TEST EQUIPMENT RISK ASSESSMENT (UK RECOMMEN-
DATION)
Users of this equipment and/or their employers are reminded
that Health and Safety Legislation require them to carry out
valid risk assessments of all electrical work so as to identify
potential sources of electrical danger and risk of electrical
injury such as from inadvertent short circuits. Where the
assessments show that the risk is significant then the use of
fused test leads constructed in accordance with the HSE
guidance note GS38 "Electrical Test Equipment for use by
Electricians" should be used.

Iso-Tech IDM 106N Specifications

General

Type	Digital Multimeter
Display	LCD
Digits	3.5
Max DC Voltage	600V
Max AC Voltage	600V
Max Current	10A
Max Resistance	20MΩ
Max Frequency	10MHz
DC Voltage Ranges	200mV, 2V, 20V, 200V, 600V
AC Voltage Ranges	200V, 600V
DC Current Ranges	200μA, 2mA, 20mA, 200mA, 10A
AC Current Ranges	200μA, 2mA, 20mA, 200mA, 10A
Resistance Ranges	200Ω, 2kΩ, 20kΩ, 200kΩ, 2MΩ, 20MΩ
Temperature Range	-20°C to 1000°C
Continuity Test	Yes
Diode Test	Yes
Safety Category	CAT II 600V
Battery	9V
Capacitance Range	20nF, 200nF, 2μF, 20μF
Frequency Range	20kHz, 200kHz
