19
3.4 Measuring resistance
1. Plu
g
the red lead into the "V-
è
-
" input terminal and the black lead into the "COM" input terminal .
2. Turn the function switch to "
è
"
3. To avoid incorrect measurements, make sure that the circuit to be measured is not live.
4. Appl
y
the probes to the item whose resistance is to be measured. To measure low resistances with the
g
reatest possible
accurac
y
, before makin
g
a measurement short the probes to
g
ether and make a note of the resistance shown (the resis-
tance of the leads). After makin
g
the measurement subtract this resistance from the fi
g
ure shown on the displa
y
.
3.5 Continuity testing with the internal sounder .
1. Plu
g
the red lead into the "V -
è
-
" input terminal and the black lead into the "COM" input terminal .
2. Turn the function switch to "

".
3. Appl
y
the probes to the circuit to be tested. The internal sounder will operate if the resistance is less than 50
è
.
