IPS X303 Series Instruction Manual
36
SAVE/RECALL SETUP
Save Setup
The front panel settings can be stored into one of the four internal
memories.
The following list shows the setup contents.
Independent / tracking series / tracking parallel mode
CH1/CH2 knob selection
Fine/coarse editing mode
Output voltage/current level
The following settings are always saved as “off”.
Output on/off
Front panel lock/unlock
Buzzer on/off
Press one of the 1 to 4 Memory keys for 2
seconds, for example memory 1. The panel
settings are saved in memory 1 and the key LED
turns on. When the panel settings are modified,
the LED turns off.
RECALL /
MEMORY
SAVE
1
2
3
4
RECALL /
MEMORY
SAVE
1
2
3
4
When a setting is stored, the output automatically turns off.
