COOLING SYSTEM

Important Operations

126

3. Cooling Fan Center

Remove the fan center with a bench press and a bar.

4. Impeller and Seal Unit

Remove the impeller and seal unit with a bench

press and bar.

Note:

Do not drive out the impeller with a hammer. Damage to

the impeller will result.
