ENGINE ELECTRICALS

9. Brush Holder

Using long-nose pliers remove the 4 brushes.

153

13. Bearing retainer

Remove the bearing retainer, then remove the pin-

ion from the gear case.

14. Snap Ring

Remove the snap ring using a screw driver or

equivalent, then disassemble the pinion assembly.
