SERVICE AND MAINTENANCE
- 5–15 -
Radiator core
Intercooler core
Fin
WARNING
• Make sure to turn the engine off
and remove the key from the
starter switch before cleaning
cores.
• The engine, exhaust pipe and
radiator will be hot immediately
after the vehicle is driven. Be
careful around these parts to
prevent burns. Clean the engine
when it is cold.
CAUTION
• Do not clean the radiator,
intercooler and their surrounding
areas using water that is supplied
under high pressure. Doing so may
cause damage.
• When cleaning the radiator core and
intercooler core, do not crush or
damage the fins.
• The fins are very fragile so be
careful not to bend them out of
shape. If they become deformed,
their cooling efficiency will be
impaired.
• Before cleaning, take steps to
ensure that no water will splash
onto the surrounding electrical
components and wires.
• If stubborn dirt still remains even
after the radiator core and
intercooler core have been cleaned,
have the vehicle inspected and
serviced at your Isuzu dealer.
MAX
LOW
Level of battery electrolyte
The Ievels of battery electrolyte are
normal if they are flush with the ellipse
hole in the filler port. If the level is too
low, replenish with distilled water. The
battery is located in the battery
compartment in the center portion of the
left side of the chassis frame.
WARNING
The fluid in the battery is sulfuric
acid. It is dangerous. Do not spill it
on your skin or clothing. Be
especially careful not to get it in
your eyes. If battery acid should get
into your eyes, flush them with
clean fresh water and immediately
seek proper medical treatment.
