SERVICE AND MAINTENANCE
- 5–16 -
Steering wheel
Check the amount of the steering wheel
play by turning the wheel in both directions
until the tires begin to move. The standard
free play is within the range of
manual steering: 10 to 30 mm (0.39 to
1.18 in)
power steering: 10 to 50 mm (0.39 to
1.97 in)
OPT
V
at the periphery of the steering wheel
when checked with the front wheels
properly in the straight-ahead position.
NOTE
If the vehicle is equipped with a power
steering unit, the wheel free play should
be checked with the engine running.
Also check the steering wheel for play
and looseness in its mount by moving it
back and forth and sideways.
While driving check for hard steering,
steering shimmy and a tendency of the
steering to pull to one side.
CAUTION
If the steering parts have excess play
or looseness or if any abnormal
condition is noted, have the steering
system checked at your Isuzu dealer
immediately.
Parking brake lever travel
Normal parking brake travels: 6 to 8
notches
When pulled with a force of 15 kg
(33 lbs, 147 N).
When parking brake lever travel is in
excess of 16 notches, the braking is
insufficient and brake adjustment
should be performed.
QKR-IE-14424805234ALL.indb5‒16QKR-IE-14424805234ALL.indb5‒16 2017/09/2713:34:522017/09/2713:34:52
