Isuzu Q Series User Manual

SERVICE AND MAINTENANCE
- 5–55 -
Fuse
No.
12V
4JB1 MODEL ENGINE
Fuse
1 10A AIR CON
2 15A EXH. BRAKE, FUEL HEATER
3 15A REAR HEATER
4 15A AUDIO (B), DOOR LOCK
5 10A STOP LIGHT
6 10A FRT FOG LIGHT, CORNERING LAMP
7 10A TAIL LIGHT
8 10A EGR
9 10A FUEL CUT
10 15A FRONT WIPER & WASHER
11 10A TURN LIGHT
12 10A H/LAMP LEVEL
13 - -
14 - -
15 15A AUDIO (IG), CIGAR LIGHTER
16 10A METER
17 - -
18 - -
19 15A HORN, HAZARD
20 10A ABS (IG)
21 15A GENERATOR
22 10A STARTER
23 10A HEAD LIGHT RH
24 10A HEAD LIGHT LH
25 15A MARKER LAMP
26 - -
27 10A RR FOG
28 - -
Relay
No.
12V
4JB1 MODEL ENGINE
Relay
1 TAIL
2 HEAD LAMP
3 HORN
4 WIP KEY ON
5-
6-
7 GLOW
8 MARKER LAMP
9 RR FOG
10 -
11 EXH BRAKE CUT
12 CSD
13 -
14 -
15 STARTER
16 BLOWER
17 CHARGE WARNING
18 -
19 CORNER LAMP
20 EXH BRAKE
21 P/WINDOW
22 DIMMER
23 -
QKR-IE-14424805234ALL.indb5‒55QKR-IE-14424805234ALL.indb5‒55 2017/09/2713:34:582017/09/2713:34:58
