Isuzu Q Series User Manual

SERVICE AND MAINTENANCE
- 5–56 -
Fuse
No.
12V
4JH1 MODEL ENGINE
Fuse
1 25A HEATER
2 10A AIR CON
3--
4 15A AUDIO (B), DOOR LOCK
5 25A P/WINDOW
6 10A STOP LAMP
7 15A TAIL LAMPS
8 10A FOG LAMP
9--
10 10A ECU (BATT)
11 15A HORN, HAZARD
12 - -
13 15A WIPER
14 10A TURN LAMPS
15 15A ACC, CIGAR LIGHTER
16 10A METER
17 10A ECM
18 - -
19 - -
20 10A ABS
21 15A GENERATOR
22 10A STARTER
23 10A HEAD LAMP RH
24 10A HEAD LAMP LH
25 - -
26 10A ECM2
27 - -
28 20A ECM
Relay
No.
12V
4JH1 MODEL ENGINE
Relay
1 TAIL
2 HEAD LAMP
3 HORN
4 WIP KEY ON
5-
6-
7 GLOW
8-
9-
10 -
11 -
12 STARTER CUT
13 -
14 ECM MAIN
15 STARTER
16 HEATER AC
17 CHARGE (ENG RUN)
18 THERMO
19 ECU IGN
20 CORNERING LAMP
21 POWER WINDOW (model with power window)
22 DIMMER
23 -
QKR-IE-14424805234ALL.indb5‒56QKR-IE-14424805234ALL.indb5‒56 2017/09/2713:34:582017/09/2713:34:58
