5A–16
BRAKE CONTROL SYSTEM
DATA LIST
The data displayed by DATA LIST are as follows:
Display
Content OK/NG Criteria for Data
Front Left Wheel Speed
Front Right Wheel Speed
Rear Wheel Speeds
km/h (MPH) D Start the vehicle and make sure of linear change in
each wheel speed.
D Turn each wheel by hand and make sure that each
speed data change.
Warning Lamp ON/OFF D To be OFF usually
ABS State ON/OFF D To be OFF usually
ABS Relay Active/Inactive D To be Active usually
4 Wheel Drive Active/Inactive D 2WD: Inactive
D 4WD: Active
Brake Switch Active/Inactive D Inactive (Released)
D Active (Pressed)
Brake Fluid Level Normal or not D To be Normal usually
Return Pump Active/Inactive D To be Inactive usually
DRP (Dynamic Rear Propor-
tioning)
Active/Inactive D To be Inactive usually
Rear Dump Valve Commanded
Active/Inactive D To be Inactive usually
Rear Dump Valve Feedback
Rear Isolation Valve Comman-
ded
Rear Isolation Valve Feedback
FL Dump Valve Commanded
Active/Inactive D To be Inactive usually
FL Dump Valve Feedback
FL Isolation Valve Commanded
FL Isolation Valve Feedback
FR Dump Valve Commanded
Active/Inactive D To be Inactive usually
FR Dump Valve Feedback
FR Isolation Valve Comman-
ded
FR Isolation Valve Feedback
G–Sensor Voltage D 0.00V when vehicle is stopped
Battery Voltage Voltage D Between 10–16.9V
