ITech IT6300 Series

Function and Features
Copyright © Itech Electronic Co., Ltd. 24
 Parallel (Parallel mode)
This function configures the instrument for parallel operations of three
channels. Possible combination mode is CH1+CH2, CH2+CH3, ALL.
Press button to confirm your set. And press to quit the
operation.
Take CH2+CH3 as an example, press (Shift) + (Menu) and
select Comb and then press to confirm. Select CH2+CH3
item and press to confirm. The front panel will indicate
“Parallel Success!” and escape this screen after 2S.
Front display as follows in condition of output off and meter state.
Wiring in Parallel mode (CH1+CH2)
 Track (sync output setting)
This function configures the instrument for tracking operations of three
channels. Possible combination mode is CH1+CH2, CH2+CH3, ALL.
Press button to confirm your set. And press to quit the
operation.
Before setting the track mode, you need to set the voltage and current of
Enter
Esc
I-setI-set
Enter
Enter
Enter
Esc
