Quick Start
Copyright © Itech Electronic Co., Ltd. 13
2. Set the current value (≥0.01A).
3. Enable the outputs
Press to let the ON annunciator and the CV annunciator turn on
to light.
4. Turn on Meter mode
Press to light the button, the Meter status Mark light on the display
is turned on.
5. Set the voltage level.
Set different voltage values, check the voltage value displayed on the VFD
is close to the voltage value you set.
6. Ensure that the voltage can be adjusted from zero to the full rated value
Current Output check
The following steps check basic current functions with a short across the power
supply’s output.
1. Turn on the power supply
2. Enable the output
Press key to ensure that the output is disabled. At the same time,
the OFF status mark is on the VFD.
3. Connect a short across (+) and (-) output terminals with an insulated test
lead, use a wire sufficient to handle the maximum current.
4. Adjust the voltage value to 1V.
5. Turn on the power output.
Press key to ensure the output is enabled, at the same time
there is CC status sign on the VFD.
6. Turn on Meter mode
Press to light the button, the Meter status Mark light on the display
is turned on.
7. Adjust the current value
Set some different current values, check whether the voltage value on VFD
is near 0v, and the current on it is close to the value you set.
8. Make sure that the current can be adjusted from 0 to full rated value.
9. Turn off the output of the power supply, and remove the short wire.
