Functions and Characteristics
Copyright © Itech Electronic Co., Ltd. 15
rated value. Press button, it will be lit. Now, there are three ways to set
the voltage:
Solution1: press button-------press button to adjust the
cursor’s position--------press and button to increase or decrease the
setting value.
Solution2: press button------press button to adjust the
cursor’s position------adjust the knob to increase or decrease the setting value.
Solution3: press button+ number to to set the voltage
value. Then press button to confirm.
3.4 Current setting
IT6800A/B series power supply enables customer to set current from 0V to
rated value. Press button, it will be lit. Now, there are three ways to set
the voltage:
Solution1: press button-------press button to adjust the
cursor’s position--------press and button to increase or decrease the
setting value.
Solution2: press button------press button to adjust the
cursor’s position------adjust the knob to increase or decrease the setting value.
Solution3: press button+ number to to set the voltage
value. Then press button to confirm.
3.5 Output on/off
button is used to control the output of power supply. When
button is lit, it represents output has been turned on. If button is dark,
it indicates that output is off. In output on mode, the indicator light CV or CC will
be lit.
Note: Please ensure the power supply and DUT has been connected well and
then press button to turn on the output.
3.6 switch the actual/setting value display
button is used to switch the display between actual and setting value.
When button is lit, it shows actual voltage and current on front panel.
Meanwhile, VFD will appear a marker of “meter”. When button is dark,
it shows setting voltage and current on front panel.
3.7 CC/CV mode
According the ohm’s law, output current is determined by output voltage and
the resistance of load. When actual current is less than the setting value, power
supply will function in CV mode. And CV status indicator lamp will be lit.
If actual current is above the setting value or rated value, power supply will
change to CC mode, and CC status indicator lamp will be lit.
