ITech IT8511+ User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 59
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
400W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic
mode
CC mode
T1&T2
100uS~3600S /Res:1 uS
Accuracy
10Us+100ppm
Rising/Falling
slope *4
0.001~0.15A/uS
0.01~1 A/uS
Minimum rise
time *5
≒50uS
≒60uS
Measuring range
Readback
voltage
Range
0~18V
0~150V
Resolution
0.1 mV
1mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback
current
Range
0~6A
0~60A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
Readback
power
Range
400W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
Protection
≒420W
OCP
Protection
≒6.6A
≒66A
OVP
Protection
≒165V
OTP
Protection
≒85℃
Specification
Short
Current( CC )
≒6.6/6A
≒66/60A
Voltage( CV )
≒0V
Resistance( C
R )
≒30mΩ
Input
Impendance
≒280KΩ
Dimension
214.5mm*88.2mm*453.5mm
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is: (1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08))
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current.
*5 Minimum rise time: 10%-90% current rise time
Model
IT8513B+
Rated value
( 0~40 ℃)
Input voltage
0~500V
Input current
0~3A
0~30A
Input power
600W
Minimum
operation
value
0.3V at 3A
3V at 30A
CV mode
Range
0.1~50V
0.1~500V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CC mode
Range
0~3A
0~30A
