19
4
th
byte
The lowest byte of time value in timer. (1 represent 1S)
5
th
byte
The highest byte of time value in timer.
From 8
th
to 25
th
byte
System reserve
26
th
byte
Sum code
Time unit in Timer is S, 1S is represented by 1.
21. Disable / Enable timer of FOR LOAD ON (52H);
Enquire timer state of FOR LOAD ON (53H)
1
st
byte
Start bit ( AAH )
2
nd
byte
Address (0—31,0XFF)
3
rd
byte
Command（52H/53H）
4
th
byte
Timer state (0:OFF,1:ON )
From 5
th
to 25
th
byte
System reserve
26
th
byte
Sum code
22. Set communication address (54H)
1
st
byte
Start bit ( AAH )
2
nd
byte
Address (0—0XFE)
3
rd
byte
Command （54H）
4
th
byte
New communication address (0~31)
From 5
th
to 25
th
byte
System reserve
26
th
byte
Sum code
23. Enable/Disable LOCAL control mode. (55H)
1
st
byte
Start bit ( AAH )
2
nd
byte
Address (0—31)
3
rd
byte
Command（55H）
4
th
byte
State of LOCAL button(0:disable,1:enable “)
From 5
th
to 25
th
byte
System reserve
26
th
byte
Sum code
24. Enable / Disable remote sense mode. (56H)
Enquire the state of remote sense mode. (57H)
1
st
byte
Start bit ( AAH )
2
nd
byte
Address (0—31,0XFF)
3
rd
byte
Command（56H/57H）
4
th
byte
Remote mode state (0:OFF,1:ON)
5
th
to 25
th
byte
System reserve
26
th
byte
Sum code
25. Set / Enquire trigger source. (58H/59H)
1
st
byte
Start bit ( AAH )
2
nd
byte
Address (0—31,0XFF)
3
rd
byte
Command （58H/59H）
