Quick Start
Copyright © Itech Electronic Co., Ltd. 19
If the fuse is fused, replace it with a fuse of the same specification
according to the model. The fuse and model matching information is
shown in the table below.
Model
Fuse specification
(220VAC)
Fuse specification
(110VAC)
IT8511+
T0.5A 250V
T1.25A 250V
IT8511A+
T0.5A 250V
T1.25A 250V
IT8511B+
T0.5A 250V
T1.25A 250V
IT8512+
T0.5A 250V
T1.25A 250V
IT8512A+
T0.5A 250V
T1.25A 250V
IT8512B+
T0.5A 250V
T1.25A 250V
IT8512C+
T0.5A 250V
T1.25A 250V
IT8512H+
T0.5A 250V
T1.25A 250V
IT8513A+
T1.25A 250V
T2.5A 250V
IT8513B+
T1.25A 250V
T2.5A 250V
IT8513C+
T1.25A 250V
T2.5A 250V
IT8514B+
T1.25A 250V
T2.5A 250V
IT8514C+
T1.25A 250V
T2.5A 250V
IT8516C+
T2.5A 250V
T5A 250V
After replacement, install the fuse box back to original position, as
shown below.
